New & Improved NanoScan II – Handheld Magnetic Wheeled Encoded Scanner

NanoScan II

Handheld Magnetic Wheeled Encoded Scanner

AUT Solutions is pleased to announce the release of the all new and improved NanoScan II scanner, the NanoScan II. We at AUT Solutions have taken this scanner to a whole new level. Please read the following bullet points about all of the changes made that improve the functionality and reliability of this scanner compared with the previous model.

Encoder Upgrades

  • Modular high resolution non-contact encoder, designed and made here at AUT Solutions, is completely IP68 water sealed with no moving part so it will not fail. We trust the reliability so much it will come with a life time warranty.*
  • The encoder now comes with a connector, so longer encoder cables can be used or cables can be replaced if damaged. Cable can be sold as a spare part to a kit so the technician can replace it in a few minutes to finish the job, no down time to the customer!
  • An optional high temp encoder housing can be purchased which has an air inlet port to allow the scanner encoder to be cooled with air for high temperature applications; up to 500F. The user’s manual has instructions on how to set this up and operate.

*Warranty does not cover encoder damaged from excessive heat.

Quick change modular design

  • The scanner comes with quick change gimbles so the gimbles can be removed in seconds and can now be mounted to the front or the side of the scanner, perfect for Phased array, TOFD and now B-scan applications.
  • The handle can also be quickly removed with no tools if scanner height is an issue for tight clearances jobs.

We added removable springs to the design so a down force can be applied to the probe if needed. If not, simply remove the spring.New and Improved Nozzle Attachment

Enclosed drive train

  • The previous design had exposed wheel gears, which had a tendency to get dirty and needed to be cleaned out frequently. The gears are necessary in the design to sync both wheels to the encoder to ensure minimized encoder count loss if a wheel was to slip. With the new design, the gears are enclosed within the assembly so no maintenance is needed and no grit or dirt can get to them.

Light weight and simple bar

  • Two scanner trucks can be linked using only one arm bar now, where as in the previous design two bars were needed. A simple hinge was added to link the bars allowing the scanner to form fit to many different types of geometry, including axial scanning of a weld seam. The scanner kit will also come with a set of longer bars in the event more probe separation is needed for dual phased array or TOFD inspections.​

Email us at sales@autsolutions.net, call us at 281-346-8091 or visit our website AUT Solutions to see our complete line of UT products, accessories and services.

AUT-NDT SYSTEM PROMOTION

AUT System Promotion

AUT Solutions is dedicated to providing our customers an affordable solution for automated corrosion mapping inspection equipment by offering a package deal valid until August 31st.
We offer a complete AUT system package which includes:
  • AccuScan 2 -axis automated scanner with 20″ arm
  • 100ft umbilical and motor controller
  • ProScan-XT single channel flaw detector with software to display A, B and C-scan, TOFD and Short Range Guided wave data with 2-axis encoding all powered via USB connection
  • High performance Lenovo ThinkPad laptop
  • 3 BSP transducers (2.25, 5 and 10MHz) with a probe skid and UT cable; a 1.5″
  • 1.5” calibration block AUT Calibration block.

Everything you need to perform high speed and very accurate automated corrosion mapping inspections, all at a special system kit price of$49,999.95.

AUT Solutions also offers a Lease-to-own program for qualified customers.  The lease program requires a down payment of 20% and is financed over a 24-month term at an 6% interest with a $1 buyout at the end of the term.

Equipment price: $49,999.95*

Down payment required: $9,999.99
Monthly payment: $1,772.78
Payment term: 24 months
Interest: 6%
Buyout (at end of term): $1
* Sales tax will be applied when applicable

If you have a need for a custom scanner, please don’t hesitate to contact us at 1-281-346-8091  or sales@autsolutions.net

All our scanners are proudly designed, manufactured and assembled in the USA

AUT SOLUTIONS HYDROFORM HOLDER

AUT Solutions is pleased to announce a simple yet effective way to attach your Olympus HydroFORM cart to our automated AccuScan and AccuTrak industrial scanners.




Allowing you to use many of your existing AUT scanner components by adapting the cart in either direction you can raster scan or index circumferential scan creating an automated phased array solution. The kit is comprised of a longer fork adapter bar and two custom fork arms which adapt to the current probe holders.

For more information contact sales@autsolutions.com or call us at 1-281-346-8091.

NEW PRODUCT ALERT: REVOLVER SCANNER

AUT Solutions is pleased to announce thew release of our latest manual phased array scanner, the Revolver.



Simplicity is the key with the Revolver, you simply select the band and wedge size as required, and within minutes you are ready to scan; no complex setup or templates are required, just snap the scanner on the pipe and scan away.



All Revolver components are machined from high grade aluminum and have an anodized finish to ensure long life and durability. Users can configure the Revolver for a single side phased array inspection or dual for complete weld coverage.



The encoder used is rated to IP68 and is designed to operate in many types of industrial conditions. The Revolver Scanner was designed to inspect small diameter pipe/tube welds, ranging from 0.80” inches to 4.50” [20mm-115mm], and has a low profile height to operate between obstructions as low as 0.625” [16mm], such as boiler tube inspection.





For more information, please contact us at sales@autsolutions.net
Download PDF brochure HERE
Visit the Revolver page HERE

OMNISCAN DATA CONVERTER TOOL

AUT Solutions is proud to announce the release of our new software feature for the ProScan Analysis Software, the OmniScan Data Converter tool.
Our good friends at Olympus have given us the ability to convert Omniscan 0-degree data (.OPD and .OUD) into the ProScan data file format so analysis can be done utilizing the industries best corrosion mapping software, the  ProScan Analysis software.  This feature will allow Omniscan owners to analyze data faster and more effectively utilizing all the tools and features the ProScan software offers.
Click the link to download the PowerPoint presentation to see everything this tool has to offer:
Having trouble with the Power Point File? Download the PDF version instead:
